| Cloud ID : | 10557 |
| Vehicle : | Foton Gratour, v55 (2019) |
| Engine : | Gasoline (N/A L), 4 cylinders (1-3-4-2) |
| Engine Code : | DAM15RD |
| Note : | Engine idling |
| Type : | Automotive |
| Oscilloscope : | HS512 Max |
| Rate : | 150 kS/s |
| Samples : | 7,878,140 |
| File Size : | 14.72 MB |
Date : 2026-10-15
| Cloud ID : | 10500 |
| Vehicle : | Daihatsu Terios, F710 (2008) |
| Engine : | Gasoline (1.5 L), 4 cylinders (1-3-4-2) |
| Engine Code : | 3SZ |
| Note : | VVT OCV Connected |
| Type : | Automotive |
| Oscilloscope : | HS512 Max |
| Rate : | 18.75 kS/s |
| Samples : | 169,388 |
| File Size : | 942.56 KB |
Date : 2026-09-15
| Cloud ID : | 10479 |
| Vehicle : | Volkswagen Caddy (2005) |
| Engine : | Diesel (1.9 L), 4 cylinders (1-3-4-2) |
| Type : | Automotive |
| Oscilloscope : | HS512 Max |
| Rate : | 150 kS/s |
| Samples : | 372,334 |
| File Size : | 845.83 KB |
Date : 2026-09-06
| Cloud ID : | 10478 |
| Vehicle : | ZX RAV4 (2010) |
| Engine : | Diesel (2.2 L), 4 cylinders (1-3-4-2) |
| Engine Code : | 2ad-fhv |
| Note : | Engine knocking when hot or when cooling fan starts. synch on cylinder 1 |
| Type : | Automotive |
| Oscilloscope : | HS512 Max |
| Rate : | 37.5 kS/s |
| Samples : | 628,014 |
| File Size : | 2.22 MB |
Date : 2026-09-06
| Cloud ID : | 10289 |
| Vehicle : | Fiat Linea (2005) |
| Engine : | Gasoline (1.3 L), 4 cylinders (1-3-4-2) |
| Engine Code : | 1.3D MultiJet |
| Note : | Loose Timing Chain. Notice the CMP falling edge relative to the cranking index at the beginning of the crankshaft rotation and compare to the same edge past second turn |
| Type : | Automotive |
| Oscilloscope : | HS512 Max |
| Rate : | 37.5 kS/s |
| Samples : | 1,016,328 |
| File Size : | 1.98 MB |
Date : 2026-06-19
